150W Mini Beam LED Moving Head Light Disco Party KTV

Quick Detail

The MINIBEAM 150 features a 7500K 150W LED with high intensity and efficiency. It produces very high light output, through a specific 2° optic system. The PAN/TILT integrates in fast and quiet movement. It offers a full complement of professional characteristics, including a static gobo wheel, color wheel, 8-facet prism, linear electronic focus, 0-100% linear LED dimmer, variable speed shutter/strobe.

Features

> A 150W white LED lamp, 7500K

> 50000 hours life span and low power consumption

> 8/16 bit smooth and precise resolution for PAN/TILT movement

> 360°/540°/630° PAN and 90°/180°/270° TILT movement

> PAN/TITL inversion available

> Scan position memory, auto reposition after unexpected movement

> Specific high precision glass optic system with 2° projection angle

> Improved optics and flat beam field

> 1 Static gobo wheel with 17 gobos plus open

> 1 Color wheel with 11 colors plus open

> Variable direction rainbow effect with speed adjustable

> 2.5m -30m electric focus

> 8-Facet prism with variable speed and direction

> 0-100% linear LED dimmer

> 25T/sec high speed LED shutter*strobe effect with variable speed

> Preset variable/random strobe and dimming pulse effect

> 11/13 DMX channels USITT DMX-512

> DMX512, master-slave, and sound activated controllable or auto operation

> DMX recorder and edit function integrated

> Blue background LED display

> Powercon connector IN

> 3-pin XLR connectors IN/OUT

> Fan cooling system

> Constant temperature readout and management function

> -35°C~45°C max ambient temperature

> IP20 protection rating

> 55dB at 3’dB rating

> 2*1/4 turn fastening Omega clamps

> 1*Safety attachment point

Specification

> Input Voltage:AC90-260V 50/60Hz

> LED Quantities:1*150W white LED

> Control Signal:DMX512,master-slave and sound activated or auto operation

> Control Channel: 11/13 DMX channels USITT DMX-512

> Power Consumption:210W

> Dimensions:183(D)*298(W)*417(H)mm

> Packing Dimensions:400(D)*510(W)*280(H)mm

> Net Weight: 11kg

> Gross Weight: 12.5kg

Applications

Disco and Club, Band performance, Stage show, Road show, Live concerts
